A COAT RACK DESIGNED FOR AND BY THE CHILDREN OF THE LA-LE-LI CENTER

A COAT RACK DESIGNED FOR AND BY THE CHILDREN OF THE LA-LE-LI CENTER

Flexpipe is proud to have partnered with the Educational Help La-Le-Li Center in Farnham to host a coat rack building workshop. The center had expressed a need for storage for the coats, boots and lunch boxes of the young people who frequent the premises. We therefore imagined together the ideal coat rack for their needs and planned the workshop day.



In this picture, France Gagné, Mireille Belleau, the children of the La-Le-Li center, and the Flexpipe team members



The workshop took place on a pedagogical day that coincided perfectly with International Day of Education. 10 young people between 6 and 11 years old were able to participate in the construction of their coat rack. They were also able to proudly sign the top of the piece of furniture in turn to reinforce the feeling of accomplishment that inhabited them.



The activity was intended to be fun, imaginative and inclusive for all ages. Young people will have put their creativity, their dexterity... and their strength to the test!



The La-Le-Li Center is an educational support center for elementary-aged children in the Municipality of Farnham. Thanks to dedicated volunteers, children can benefit from personalized assistance adapted to their needs. Whether it's homework help, tutoring, or activities during pedagogical days. All interventions are dedicated to supporting the parent in his role as educator. It's a great local initiative that we want to support, because we believe we can help make learning possible in a fun and concrete way!







Using Flexpipe for Lean Manufacturing CabinetMakers

Using Flexpipe for Lean Manufacturing CabinetMakers

Implementing lean is a journey in itself. No company goes from 0 to 60 in record time when implementing lean principles. They learn, get better, learn some more and then improve some more. Each step of that journey is made easier when senior management is entirely on board and, in some cases, driving the lean journey.




ADOPTING LEAN MANUFACTURING
Regardless of your industry, some employees may be reluctant to change, while others may embrace it. For those who resist change, it’s often a question of personal comfort; we’ve always done it this way, so why change? However, with consistent training, constant feedback, daily upgrades, and commitment, you will achieve significant lean improvements using Flexpipe.

Flexpipe is a tool, but the employees drive the improvements

Here are just a few examples of lean improvements using Flexpipe products.

Source: MetCabinet About Us

[caption id="attachment_40677" align="alignnone" width="1280"] Look and feel Lean with clear floor lines.[/caption]
INCREASE PRODUCTION FLOOR SPACE BY REDUCING OVER-PRODUCTION
Several cabinet makers using Flexpipe can decrease over-production while dramatically reducing the square footage of their shop floor. This reduction in floor space saves the company money while making it easier to manage materials, quarantine defective products, collect scrap or refuse, and move semi-finished and finished goods between lean work cells.

We often come across Cabinet makers who have fully adopted batch production. Trying to make different types of products simultaneously, along with redundant work processes and poor material flow, often leads to WIP cabinets, drawers, trims, and sides strewn about the shop floor. We see this quite often. The solution to this issue is provided below

Learn about one-piece flow and how it could be put in place.
Make sure management and owners are on board with the new one-piece flow philosophy.
Be ready and open-minded to adjusting work tasks, departments, and different production and assembly activities.

[caption id="attachment_40681" align="alignnone" width="1280"] The Flexpipe cart holds a day’s worth of nailer boards for final cabinet assembly. Vertical bins for longer parts where different parts are clearly separated and labeled to save time as opposed to searching around aimlessly (nonvalue added). A measurement label is placed alongside the Flexpipe structure to quickly identify and measure parts (visual management).[/caption]



[caption id="attachment_40685" align="alignnone" width="1280"] Color-coded structures help operators and technicians immediately determine the urgency of customer orders. The blue drawer carts are for orders with standard lead times, while the red carts are for urgent or rush orders (visual management). All parts are labeled on the pipes with AL-TAG2 and a non-marking marker is put on the cart for identification.[/caption]

[caption id="attachment_40824" align="alignnone" width="1280"] Flexpipe modified 5S Takt board complete with work order instructions, layouts, and plans.[/caption]

This Flexpipe cart in the finishing department is used for cabinet frames, end panels, backs, shelves, etc. Each subcomponent and material is neatly placed in its appropriate slot, making it easy for operators to access a given piece when needed.
OPTIMIZE MACHINE UTILIZATION WITH EFFICIENT CHANGEOVERS
Companies invest a lot of money in automating their machinery and equipment. Unfortunately,   these same companies often ignore the lean structures and material handling solutions critical to maintaining running equipment. They simply don’t invest enough time, energy, or money to ensure that their material handling structures are optimized.

Even the newest automation falls short if the structures around them aren’t properly organized. Not convinced? Take some time to investigate and measure your cutting machine’s productivity and efficiency. You’re likely to find there is far more downtime than you expected. Very often this is due to inefficient changeovers.

Review your loading and unloading procedures. Focus on ergonomics so that operators have easy access to tools and work instructions and never have to wait for one-at-a-time forklift deliveries of raw materials.
Have the next job (complete with material and work orders) ready well in advance to reduce waiting time.
Try to put as much as possible every day on casters to give you flexibility and reduce waiting time.

[caption id="attachment_40739" align="alignnone" width="1280"] Tape storage placed within the work cell allows for immediate replacement of consumables.[/caption]

A Flexpipe cart on the Homag Edgebander machine at Superior Cabinet. It applies matching edge tape of various colors to the sides of the melamine to match the finish on the top and bottom.Source: Superior Cabinet.

[caption id="attachment_40751" align="alignnone" width="1280"] Load or unload materials with a pallet stand on wheels to avoid waiting for a jigger or forklift (non-value added).[/caption]

[caption id="attachment_40755" align="alignnone" width="1280"] Flexpipe Manual cutting table with a 5S shadow board.[/caption]
USING WORKER CREATIVITY TO BUILD A LEAN CULTURE
You will never sustain a lean culture if you don’t engage, train, and spend on your employees. The woodworking industry has so many talented, hard-working, resourceful, and creative people. Unfortunately, there are often underutilized. This unused worker creativity is by far the biggest waste in the industry.

Several companies have highly-skilled and experienced employees who have decades of experience. While experience is important, it can sometimes lead to an unwillingness to adopt change. Again, the mindset becomes, “Why change anything when it has been working for  25 years?’’. Here are some guidelines to make sure all employees are speaking the same language.

Train workers, so they can name and spot the 8 most common causes of waste.
Get employees into a routine by holding a daily meeting where the agenda covers the previous day’s improvements and any KPI.
Engage workers and make them take part in small Kaizen events. This is a great opportunity to test out ideas, modify structures and learn from mistakes.

[caption id="attachment_40764" align="alignnone" width="1280"] Customized Flexpipe cart with multiple slots for easy access to materials.[/caption]

Rack design by Michael Kachur – Continuous Improvement Manager and certified Lean Champion at Superior Cabinets in Saskatoon, Canada.

[caption id="attachment_40829" align="alignnone" width="1280"] Customized Flexpipe structure holding bins and securing semi-finished cabinet glass frames.[/caption]
ELIMINATE WASTED TIME BY INCREASING ASSEMBLY PRODUCTIVITY
Within the woodworking industry, it’s common to devote money and resources to storage, trimming or cutting departments while the packaging department is left with too few resources or focus.

Assembly is a labor-intensive activity where small incremental changes can have a large impact. Most importantly, these changes don’t involve changing the layout of the shop floor.

Creating a custom-made lean work cell or workstation reduces unnecessary movement and excessive walking. When lean work cells are positioned near one another, it reduces transit time for work-in-process parts. 5S and ergonomics are critical requirements for these new lean work cells.

Get employee feedback on what they waste time on. It can be missing tools, instructions or having to walk long distances to move parts or get material.
Celebrate your accomplishments and improvements. Congratulate your employees and be proud of what you’ve accomplished.
Make these small Kaizen events a frequent occurrence.

Wood vs Flexpipe Tube and Joint System
Wood can still be used for cart surfaces or siding. However, your stations and carts should be made from Flexpipe – which is easy to adjust or modify. Flexpipe and wood are similar in price but Flexpipe is far more durable, versatile, and much stronger compared to wood. More importantly, it won’t rot or warp due to humidity and moisture.

[caption id="attachment_40768" align="alignnone" width="1280"] Wood carts can still be used for cart surfaces or siding but other structures should be designed with Flexpipe.[/caption]

Wood cart Feist Cabinets & Woodworks
ALUMINUM EXTRUSION VS FLEXPIPE TUBE AND JOINTS
You can save up to 50% with Flexpipe tubes and joints compared to aluminum material handling systems. Aluminum has the required precision for machines, equipment, and robotic integrations, but it’s far too costly for carts, racks, or workbenches. Another issue with aluminum is the tendency to have water stains over time. Flexpipe is easier for workers to use, far less expensive ($8 per 8 feet of pipe), is available in multiple colors, and will never stain.

STEEL VS FLEXPIPE TUBE AND JOINTS
Steel is a universal material with multiple applications. However, creating material handling equipment with steel requires welders and painters. Changing existing welded structures is even more costly and time-consuming.

With Flexpipe, there’s no need for welders or painters. There’s no need to spend an inordinate amount of time trying to modify an already welded structure. Anyone with a little creativity can cut or assemble pipe and joints in a fraction of the time and costs compared to welded structures.

You can quickly put in place improvements and change your Flexpipe structures every day as ideas and suggestions come forth. No need to scrap old, welded structures. No need to re-weld existing structures. The changes you make to a Flexpipe structure in the afternoon can have you up and running in the morning.

[caption id="attachment_40805" align="alignnone" width="1280"] Bare steel - exposed to the environment - will eventually corrode and rust. Flexpipe's products never corrode or rust and there is never any painting of a Flexpipe structure as the piping is available with multiple colors of plastic coating.[/caption]
SIMPLIFYING LEAN MANUFACTURING ADOPTION WITH FLEXPIPE'S MODULAR SYSTEM
Flexpipe is widely-recognized among North American manufacturers as a modular, scalable, easy-to-use, and inexpensive material handling solution. The company's free design extension for SketchUp allows manufacturers to custom-design and build their own tube and joint material handling structures. Customers rely upon Flexpipe's team for its design acumen, speed of response, and the company's cost-effective solutions.

If you would like to see how Flexpipe can help you adopt lean concepts while reducing your costs of material handling, then contact us now.

Poka-Yoke: A Time-Tested and Simple Way to Mistake-Proof Manufacturing

Poka-Yoke: A Time-Tested and Simple Way to Mistake-Proof Manufacturing

Often seen as the ideal way to ensure the error-free assembly and production of finished goods, Poka-Yoke has been a mainstay of lean manufacturing since 1960. Shigeo Shingo – a Japanese industrial engineer and expert in lean manufacturing principles and the Toyota Production System – developed a simple failsafe approach with a clear set of lean principles designed to eliminate human error while improving product quality..

So, how does Poka-Yoke work, and what role does Flexpipe’s modular and scalable tubing system play in error-proofing your manufacturing process?
The High Costs of Defects in Lean Manufacturing Environments
One of the biggest causes of waste in lean manufacturing includes defects. Sometimes they’re caused by voids, inclusions, or porosity in materials like steel, aluminum, brass, etc. These defects often appear during machining as the material is removed and the void or inclusion is exposed, which makes the part completely unworkable.

Other defects occur later down the production line during the assembly of sub-components, work-in-process parts, and other labor-related manual processes. Regardless of how or why these defects occur, the costs for manufacturers can be measured in lost production, lost wages, machine and assembly downtime, delayed product shipments, upset customers, and any costs associated with having to stop the production line.
Understanding Poka-Yoke
Some defects are entirely unavoidable. They happen regardless of how many stopgap or failsafe mechanisms are in place. These defects are often seen as “Acts of God,” which are situations where defects occur that cannot be accounted for. In this case, think of these Acts of God defects as situations nobody could have possibly anticipated.

Poka-Yoke isn’t a tool to eliminate these Act of God defects. It’s a tool to ensure that operators and technicians follow the correct process steps and that the work task is done correctly. More importantly, it’s a fail-safe mechanism that either stops human error at the source or instantly notifies the operator and technician that an error has occurred. In both cases, the emphasis is on immediately addressing the error or defect and taking corrective actions.

One type of Poka-Yoke prevents the error from occurring, while the other detects the error once it’s happened. This leads us to the two main categories of Poka-Yoke: Prevention-Type and Detection-Type.

[caption id="attachment_40868" align="alignnone" width="1280"] Customized Flexpipe Part Rack: Each portion of the rack only accepts a certain size, length, and dimensions of a semi-finished part. Images and writing on the rack define what part should be placed and the go/no-go decision - or Poka Yoke - is made by the protruding bars.[/caption]
1 - Prevention-Type Poka-Yoke
This type of Poka-Yoke is often enacted by manufacturers who have experienced previous errors. In this case, they’ve experienced human errors and know they will happen again if they don’t enact a failsafe.

In other instances, a prevention-type Poka-Yoke is initiated during the product’s design stage when engineering and production identify critical assembly or work tasks where human error is likely to occur. Either way, the idea is to prevent the error from occurring by manufacturing or buying a jig or fixture. If an error does occur, the next step is to stop the work task and quarantine the defect.

Should the operator or technician encounter another defect or error on the following product, manufacturers will often stop the process and inspect the batch or production quantity. They may then use a corrective action report outlining the cause of the defects and possible solutions.

Identify the potential for error to occur.
Create a jig, fixture, warning device, or process to capture errors.
Stop the work task once the error occurs.

2 - Flexpipe Modular and Scalable Jigs and Fixtures
One of the more common issues manufacturers encounter is making multiple jigs and fixtures to accommodate all the manual steps involved in their manufacturing process. This problem is only exacerbated when companies have an expansive product line. Unfortunately, most of these jigs and fixtures are machined or welded, making changing them labor-intensive and costly.

To avoid the high costs, time, and labor involved in changing existing welded fixtures and jigs, several companies choose to make new ones. They then retain their older jigs or have them stored or shelved. Not only does this take up valuable shelving and warehouse space, but it often leads to mislabeled or misidentified jigs and fixtures. However, there is a solution.

Flexpipe’s modular and scalable tube and joint system mean manufacturers can design, assemble, change, or modify their jigs and fixtures in a fraction of the time and at much lower costs compared to welding or machining new fixtures.

(1 & 2): Flexpipe Cart with Jet Skins Slots: Each slot can only accept a certain size, width, and dimension of skin. Operators immediately know which skin fits in its appropriate slot.

Flexpipe has multiple pipe colors, allowing manufacturers to make color-coded racks where semi-finished and work-in-process parts that have gone through the Poka Yoke process can be stored and quarantined. These 1 1/16 in (28 mm) diameter galvanized steel pipes have a polyethylene scratch-proof coating and come in white, black, blue, yellow, and red.

This “cut-to-length-and-assemble” system is easy to use and just as easy to modify or change. With a scalable Flexpipe Poka-Yoke structure, companies no longer have to retain older welded fixtures or machine new ones. No more issues with misidentified jigs. No more having to store older outdated fixtures. Instead, companies retain their Flexpipe jig and fixture designs and remake their structures when needed. It’s a saving in time, money, and space.

3: Flexpipe Numbered Flow Rack: Numbered slots and specific with specific heights ensure proper part placement. 4: Flexpipe Cart with Vertical Holders: Custom-made tug cart has vertical holders that only accept a specific width of tubes.

5: Flexpipe Cart with Molded Styrofoam: Operators can only put in subcomponent parts that fit the Styrofoam mold dimensions. If they don’t fit, they shouldn’t be on the cart. 6: Flexpipe Cart with Custom Holders: Semi-finished parts must be a certain length to fit horizontally on the cart. If the length isn’t right, it simply won’t fit.
Detection-Type Poka-Yoke
The second approach focuses on warning or notifying the operator once an error has occurred. While the first is preventative, this is a more reactive fail-safe mechanism that stops production immediately. This type of Poka-Yoke often involves equipment or electronics and is predicated on the operator receiving a warning or visual queue once the error occurs. Equipment manufacturers will often incorporate sounds, alarms, and bright red lights to notify operators of an error.

The goal is to provide warning signs in case an operator is present so that they can shut down the equipment or machinery. However, if no operator is available, the system uses a failsafe mechanism that immediately shuts down the operation.

The operator receives a warning.
Error detected immediately.
The failsafe mechanism stops the work task.

Mistake-Proofing Your Manufacturing

Adopting Poka-Yoke as an error-proofing technique will help reduce your manufacturing costs and improve product quality. Success requires your team to define every critical work task and implement a fail-safe mechanism for each of those tasks.

Identify the Work Task or Process for Poka-Yoke

Think about the critical work tasks involved in manufacturing your finished good. You probably already have steps in your production process where periodic quality inspections or reviews occur. A Poka-Yoke can remove those inspections altogether. At the very least, you’ll be able to reduce some of these inspections and rely solely upon the operator or technician.

Clear Assembly Drawings and Work Instructions

Clear top-level and sub-assembly drawings and work instructions are an absolute must. Make sure you have a quality management system that validates assembly drawings, instructions, and work tasks long before you issue work orders to production. The Poka-Yoke system will stop human errors by ensuring the work task is performed correctly and that parts and sub-components are properly aligned. However, bad assembly instructions defeat the purpose of having a Poka-Yoke.

QC-Inspected Flexpipe Structures and Calibrated Equipment

With the proper failsafe mechanism, your QC department may not have to do as many periodic inspections on work-in-process and sub-assembly parts. However, that only happens if your Flexpipe jig or fixture is periodically inspected for fit, form, and function. Over time, even the best-constructed jig or fixture will lose its dimensional tolerances. Regularly checking your Flexpipe structures means ensuring all joints, screws, nuts, connectors, and assembly components are adequately secured.

Trial Runs or Pre-Testing Flexpipe Jigs and Fixtures

Make sure you try some trial runs with your Flexpipe structure. You may need to make some slight adjustments to be sure your jig or fixture works appropriately. Bring your operators and technicians into the process and get their feedback on your Flexpipe jig or fixture's usefulness. They’ll be using it and therefore have great insight, so ensure they’re included in the process.

Clearly Defined Poka-Yoke Process Steps

While the failsafe mechanism will stop human errors from occurring, you will still need to outline the process steps technicians and operators take when an error occurs. Will you have your operators quarantine the product immediately? Will they have to call a supervisor to review the issue? How often should the operator validate future components before shutting down the assembly process? Each of these questions needs to be determined well in advance.

Flexpipe Jig or Fixture Management Program

It’s good practice to have a Flexpipe jig or fixture management program in place. It should define when, where, and how jigs and fixtures are stored and shelved, when they are replaced or refurbished, when they are inspected, and which jigs or fixtures go with their appropriate work tasks or work cells. The color-coded piping may help here. Ensuring proper nomenclature means all your Flexpipe structures are easily identified.
The Three Methods of Poka Yoke

When companies look to reduce the risk of human error and mistake-proof their manufacturing, they end up choosing between three methods of Poka Yoke. When implemented, these three methods will help eliminate the high costs of errors and defects. They are simple methods that help operators and technicians eliminate errors.
Contact Method

The contact method eliminates errors by immediately detecting defects between mating parts or individual parts based on their physical attributes. These attributes can include the part’s width, size, length, thickness, color, or design.

Examples of contact methods include USB ports, power outlets, locks only accepting one type of key, or even simple children’s toys like sorting cubes where balls and blocks must fit in specific slots.

In manufacturing environments, a contact method Poka Yoke might include switches or measurement devices that won’t allow work to begin unless the part fits or matches correctly. Companies that use shadow boards with protrusions or bars that only accept a certain sized part are examples of contact method Poka Yokes. Foam packaging in boxes is another example of where only the right dimensional parts will fit into the foam’s design.

The contact method Poka Yoke is best used for repetitive work operations. It eliminates errors and immediately notifies operators and technicians of any defective parts or misaligned parts.
Constant Number Method

The constant number method – sometimes referred to as the fixed-value method – is a type of Poka Yoke where a specific number of parts or consumables must be used in each work operation. If there are any parts left over at the end of a work operation, then an error has been made.

In manufacturing environments, kitting boxes would include several parts that must be used. If any parts remain, the integrated assembly cannot move to the next chain in the process. This type of Poka Yoke is good for work tasks that are repetitive. This means a certain number of movements and actions must be done sequentially.

An example in our everyday lives would include assembling Ikea furniture and having screws, nuts, or bolts left over or a parent assembling a hockey net or bicycle and having parts remaining.
Sequence Method

With the sequence method Poka Yoke, a predetermined number of work tasks or steps must be done sequentially before the part can move to the next operation. In several manufacturing environments, there are systems in place with switches that won’t allow an operator to proceed unless they’ve done the operation or used the parts in the proper sequence. Either the system shuts off completely or the operator is given a visual queue like a red flashing light and warning sound.

An example of the sequence method Poka Yoke might include a car providing a warning light or sound when the driver doesn’t put on their seat belt or a manual car not allowing the engine to start until the driver pushes down on the clutch. Other examples include appliances like microwaves and washing machines not operating until the door is closed.
Flexpipe’s Multiple-Use Tube and Joint System
Flexpipe Inc is a Montreal-based designer, manufacturer, and integrator of modular and scalable tube and joint systems. The company’s Flexpipe Creator Extension is an easy-to-use free design extension for SketchUp software that empowers manufacturers to design their structures. The savings in time and money means manufacturers can assemble, change, or modify structures as needed. If you would like to learn more, contact us now.

How to Sell Continuous Improvement to Senior Management

How to Sell Continuous Improvement to Senior Management

Regardless of the company – or the industry – senior managers in manufacturing enterprises need to make decisions based on cold, hard, irrefutable facts. They need numbers. They need data. They need to ensure that their decision to move forward has a high probability of success.

Senior managers need this critical information to make a go/no-go decision on capital expenditures, hiring, expansion, machine and equipment repairs, or, more aptly, for pursuing continuous improvement projects.

Learn more about the three fundamental principles needed to convince senior managers to pursue continuous improvement initiatives and how Flexpipe structures are critical to that goal with insight from Leslie Pickering and Mark Zeilinger of Quadrant 5.
Pursuing Continuous Improvement Initiatives
In manufacturing environments, waste can take many forms. It can include work stoppages, human error, misaligned or out-of-tolerance parts, poorly assembled parts, machine downtime, redundant tasks, repetitive tasks, or any action or process that inhibits the natural flow of work.

Sometimes, reducing waste in manufacturing can be as simple as reducing the transit times to move work-in-process parts between cells. It could include revamping a workstation so that the assembly process is more seamless and the operator within the workstation has easier access to materials and tools.

Regardless of what approach is taken, these changes initially seem small. However, when repeated across all work cells, these small changes quickly add up until costs are reduced, quality is improved, and more finished goods are produced. Unfortunately, because these small steps seem so inconsequential, senior managers have difficulty viewing the benefits of adopting lean concepts.

As stated by Leslie, “Senior Managers are really good at developing global views – where they can see the end game or the end goal – but they often don’t take a sequential process to how those goals are achieved – what steps need to be taken sequentially to get there. Your job in continuous improvement is explaining the steps to achieve that goal.”
A Simple Three-Step Process
Ultimately, adopting continuous improvement initiatives can be summarized in three overriding steps. Leslie states, “1. This is what is currently happening. 2. This is what we’re trying to do, and 3. These will be the benefits of implementing lean.” So, does that mean you simply verbalize these issues to senior management, and they’ll quickly agree to pursue lean initiatives? No, it does not.

These three steps are merely guidelines. You must gather the hard facts that senior managers need to implement lean. Your goal includes gathering the data and defining the metrics that will help senior managers measure the return on investment (ROI) for enacting continuous improvement across the entire production floor.
Cycle Times and Throughput Volumes Are Key

All work operations or work tasks involved in making a product have a cycle time. Lowering cycle times means you’re manufacturing more products at a lower cost. The question senior managers want to be answered is whether the savings of implementing lean are higher than the cost of implementing lean.

In our example, we’re using a basic cycle diagram (below) showing the steps for manufacturing a product. Our basic cycle diagram defines each work process or manufacturing step involved in making a fictitious product.

For the sake of simplicity, we’ll assume that each of these “steps” represents a single work cell. Each cell has a specific cycle time for a given work operation –the time it takes an operator to complete a work task.

Each cell also has a throughput volume – that volume of semi-finished parts the cell completes before those parts move to the next chain in the process.

This exercise aims to gather data on how lean initiatives can 1) Lower cycle times, 2) Increase throughput, 3) Lower manufacturing costs, and 4) Shorten the lead time to get finished goods to customers.

At the end of the exercise, you’ll have the data you need to show senior management what was happening, what you changed and why, and how making similar changes across all cells will result in lower cycle times, increased throughput, and reduced costs – or to paraphrase Leslie “the benefits of implementing lean.”
Manufacturing / Cell Productivity Rate
While operators might be paid for an 8-hour shift, they do not work a total of 8 hours. You must account for two 15-minute breaks in the morning and afternoon and then lunch. In our example, we’ll assume it’s a one-hour lunch. That leaves 6.5 hours of actual available work time.

Now, nobody can work at 100% efficiency. People go to the bathroom, get called away, or are interrupted for valid reasons. We’ll assume that the operator works at 85% efficiency. This means that the work time is 5 hours and 35 minutes.

We’ll now use that 5 hours and 35 minutes when calculating the work cell’s throughput.
1.“This is What is Currently Happening.”
Every lean process has a beginning, and we’ll assume that beginning includes you focusing on an initial assessment of a single work cell. Start by assessing the cycle times for each work task in your chosen work cell.

Ensure the operator or employee of the cell understands that your goal is to help make their job easier.

Make them feel part of the process, and they will be more than willing to show you some of the issues they come across.

Ensure they understand that this exercise is not about timing them but capturing the causes of work stoppages.

Mark of Q5, “We’re always touching on the human element. How do you get people engaged? That’s where improvements happen. Nobody knows that piece of equipment or machinery better than the operator themselves. So, you really need their input. The approach is to create “an island of excellence,” something people can point to as an example. So, give people recognition – a pat on the back and make them feel part of the continuous improvement process.”



Operation
Work Cell #1

Unit of Measure
Cycle Time in Minutes converted to seconds

Product
Widget X

Set Up-Time Minutes
Conversion of Minutes to Seconds
 Number of Work Operations
Cycle Time
Conversion of Minutes to Seconds
Comments / Notes

30
1800
1
7,00
420,00
Missing material (Operator had to search for material)

2
8,00
480,00
Missing assembly instruction

(Operator had to search for instructions)

3
25,00
1500,00
Broken SawBlade / No replacement (Operator had to leave work cell and go to stores to get replacement blade)

4
5,00
300,00
No issues - clean work task

5
5,00
300,00
No issues - clean work task

6
8,50
510,00
Missing assembly instruction

(Operator had to search for instructions)

7
9,00
540,00
Missing tool (lack of tool placement caused delay)

8
5,00
300,00
No issues - clean work task

9
5,00
300,00
No issues - clean work task

10
15,00
900,00
Missing tool (lack of tool placement caused delay)

Averages
9,25
393,90



You’re going to create your own “island of excellence” by using these initial cycle times within the cell to show the issues the operator faces daily. You’ll also capture any reasons for delays or work stoppages.

In our example, the cycle times with no issues are done in five minutes or 300 seconds. We’ve converted it to seconds because even the smallest changes that save a couple of seconds can dramatically impact.

Now, the 5-minute cycle time may not be the optimized cycle time, but for this example, it’s the best cycle time this cell produces.

However, the average cycle time at the bottom is skewed by the operations (1,2,3,6,7, and 10) that encountered work stoppages. This means these work stoppages pushed the average cycle time to 9 minutes, 25 seconds, or 555 seconds.

There is no hard and fast rule about how many cycle times you should track. In our above example, we’ve tracked ten cycle times. We’ve converted those times from minutes to seconds to simplify how we calculate how much the work cell produces.

Deduct the 30-minute setup time from our manufacturing productivity rate of 5 hours and 35 minutes.
Take the remaining 5 hours and 5 minutes and convert them to seconds. This gives us 18,300 seconds of available work time.
Now, divide the 18,300 seconds by the cycle time in seconds, which is 555. This gives us a work cell throughput of 33 units.

The table below summarizes the data you’ve gathered from the work cell. Now, it’s more than likely that you already know what a given work cell produces. You may also know what the cycle times are. Plenty of MRP and ERP software solutions provide cycle time data.

However, no software can show you how to reduce the cycle times. It can only report them. It can only provide numbers. You need to see for yourself what causes work stoppages. Only then can you enact strategies to reduce those cycle times and increase throughput.



Operation
Average Cycle Time in Minutes
Average Cycle Time in Seconds
Total Number of Seconds (5 hours 5 minutes)
Work Cell Throughput

Work Cell #1
9,25
555,00
18300
33



You now have data on a work cell that defines Leslie’s first statement: “This is what is currently happening.” You have a list of the most common delays encountered by the operator in the work cell. You know the causes of higher cycle times and can enact strategies to eliminate those causes.
2.“This Is What We’re Trying to do.”
One of your changes included making a modular and scalable Flexpipe tool storage rack. You then placed this rack immediately outside the work cell, so the operator no longer has to walk to inventory to get replacement saw blades.

Another change included making a Flexpipe workstation where all tools and consumables are easily located. You combined this new workstation with a modular flow rack so that replacement consumables and materials are always readily available.

Finally, you’ve created a modular Flexpipe work center where the operator can easily access assembly instructions.

Storage Rack: Machine Parts (Blades)
Modular Workstation
Modular Flow Rack
Modular Work Center with instructions

After making these changes, you revisit the work cell and take a new set of cycle times.

While there are still operations that encounter some delays, the overall benefit is that you have achieved more operations that meet the desired cycle time.



Operation
Work Cell #1

Unit of Measure
Cycle Time in Minutes converted to seconds

Product
Widget X

Set Up-Time Minutes
Conversion of Minutes to Seconds
 Number of Work Operations
Cycle Time
Conversion of Minutes to Seconds
Comments / Notes

30
1800
1
5,00
300,00
No issues - clean work task

2
7,00
420,00
Misaligned part - small adjustment

3
5,00
300,00
No issues - clean work task

4
5,00
300,00
No issues - clean work task

5
5,00
300,00
No issues - clean work task

6
7,35
441,00
Replacement Tool needed - easily found - small delay

7
7,30
438,00
Replacement Tool needed - easily found - small delay

8
5,00
300,00
No issues - clean work task

9
5,00
300,00
No issues - clean work task

10
14,00
840,00
Broken Saw Blade - Replacement blade in material flow rack immediately outside work cell minimized replacement time.

Averages
6,57
393,90



A new workstation made locating replacement tools easier for the operator.

Placing a storage rack for replacement saw blades immediately cut down on the time the operator took to replace the blade.

Instead of a 25-minute cycle time or “delay,” the operator merely located the replacement blade and made a change that only took 14 minutes.

Ultimately, your average cycle time was lowered to 6 minutes and 57 seconds.

The lower cycle times mean the work cell increased its throughput by 41%, from 33 to 46 units.



Operation
Average Cycle Time in Minutes
Average Cycle Time in Seconds
Total Number of Seconds (5 hours 5 minutes)
Work Cell Throughput

Work Cell #1
6,57
393,90
18300
46


3.“These Will be the Benefits of Implementing Lean.”
Increasing throughput in a work cell accomplishes nothing if the remaining work cells don’t make similar continuous improvement changes. All you’re doing is creating a backlog for the next cell in the process.

You’ve increased the cell’s throughput, but without making similar changes to the remaining work cells, it’s all for naught. At this point, you’ve gathered enough data to show how making small incremental changes can have a dramatic impact on a work cell’s throughput.

Senior managers often have little choice but to move forward on additional continuous improvement initiatives when presented with this data. It’s now very easy for them to see how repeating the process will lead to significant improvements and savings.

The costs of a Flexpipe structure include the cost of the materials and the time it takes your operators to assemble structures. That initial cost is minimal when compared to the constant returns of pursuing lean principles. The benefits of lean are forever.

As stated by Mark, “That’s what we love about Flexpipe. It’s really easy just to try something. There’s no downside whatsoever. Cut a pipe too short, and we’ll just use it elsewhere.”

Ultimately, the company would achieve the following benefits if you pursued similar continuous improvement initiatives with the remaining cells.

Increased Manufacturing Throughput: More parts are produced in a day, week, or month.
Reduced Costs: The company achieves lower manufacturing costs by increasing the number of finished parts produced within an 8-hour shift.
Shorter Lead Times: Reducing cycle times and increasing cell throughput means you’ve reduced the time it takes to provide finished goods to customers.
Improved Machine Utilization: There is nothing more costly for manufacturers than having idle machinery. In the example above, having consumables and spare parts for machinery immediately outside the work cell helped to reduce the time the machine was sitting idle.
Better Ergonomics and Safety: Poorly constructed work cells often include hazards that lead to human error and injuries. Worker injuries and absenteeism cost manufacturers $1,100.00 per day per worker. Take the number of missed days due to injury over a given year and use that amount as further justification for pursuing continuous improvement initiatives.

Cost-Effective Flexpipe Material Handling Solutions
Flexpipe is a Montreal-based supplier, designer, and integrator of modular, scalable tube and joint systems for material handling. The company’s customer-centric focus and proactive approach empower manufacturers to make their structures at a fraction of the cost compared to fixed material handling systems.

The company’s free design extension for SketchUp is easy to use and provides a complete assembly drawing, material cost breakdown, and bill of materials.

If you would like to see how Flexpipe can help on your next continuous improvement project, contact us now.

About our Lean expert - Leslie Pickering

Mr. Pickering holds a degree in Mechanical and Production Engineering. He brings 35 years of experience in international process improvement, manufacturing, and operations. He is a recognized Toyota Production System specialist and is highly regarded as a Subject Matter Expert in the areas of Lean Manufacturing.

About our Lean expert - Mark Zeilinger

Mr. Zeilinger holds a degree in Mechanical Engineering. He brings over 30 years of experience in manufacturing and operations. Mr. Zeilinger is a recognized Toyota Production System Specialist, who has implemented successful transformation methodologies across a wide variety of industries, including Packaging, Electronics, Construction, Plastics, Food, Automotive, and Aerospace.

Critical Steps to Choosing Material Handling Systems

Critical Steps to Choosing Material Handling Systems

Different types of material handling solutions, equipment, and machinery are used within supply chains to move, store, protect, control, and handle materials. The goal is to ensure that materials are readily available and that parts and finished goods are properly protected during transit to and from warehouses. Material handling is a critical component for manufacturers, warehousing, wholesalers/distributors, resellers, and retailers.


What is a Material Handling System?
A material handling system includes any equipment, vehicle, standing structure, storage unit, rack, or trolley involved in storing, transporting, and protecting materials, consumables, and finished goods. For manufacturers, a material handling system should be designed with short-range movements in mind. This means that production employees should be able to easily access and move raw materials, consumables, and work-in-process parts.
Why Is Material Handling Important?
Material handling is a critical component of protecting against damage to parts, raw materials, and consumables. This not only saves companies money but also improves final product quality by reducing defects. Material handling solutions should be part of a larger company-wide program to improve a company’s storage and handling practices. Only a proactive storage and handling process can protect against unforeseen and costly part damage.
Material Handling Systems Across a Supply Chain
Material handling solutions should simplify employee access to materials and parts so that the speed of work increases. Ideally, these systems should also be easy to modify and scalable to keep up with changing requirements. Across a given supply chain, material handling solutions are heavily relied upon as a means of meeting delivery requirements with minimal product defects.

1 . Production and Manufacturing
Material handling systems found in manufacturing include carts, flow racks, racks, tuggers, shelving, workbenches, workstations, boards, and other storage solutions. Each of these systems plays a critical role in supporting production employees by supplying them with the necessary tools, instruments, parts, instructions, and consumables to complete work orders.
2. Packaging and Transportation

Manufacturers typically ship their industrial finished goods on strapped pallets of corrugated cardboard containers. Corrugated containers and customized packaging are often used as a means of protecting materials from damage during transportation. They are also the most cost-effective way of transporting industrial finished goods. Strapped corrugated pallets help keep raw materials, consumables, and parts safe during transit.
3. Storage and Warehousing
The most common types of warehouse material handling systems include forklifts, lift trucks, hoisting equipment, shelving, pallets, pallet jacks, automated guided vehicles (AVG), and even robotic handling systems. Forklifts are the all-important vehicle in warehouse management. These are heavily relied upon to move corrugated and strapped pallets, while lift trucks can position pallets on high vertical shelves.
4. Wholesalers and Distributors
Wholesalers, distributors, and bulk resellers rely upon a combination of material handling solutions. Distributors typically use forklifts, lift trucks, and hoisting equipment to handle and store shipments. These are then broken down into smaller shipments which are then sent out to retailers. The focus is to minimize costs so incoming bulk shipments are often used as a means of lowering per-unit freight costs.
5. Retailers
Large retailers with large warehouses typically rely upon forklifts and lift trucks in addition to large shelving and storage units as a means of controlling finished goods. Smaller retailers may simply require pallet jacks, commercial hand trucks, warehouse stock carts, or small utility carts.
Problems with a Fixed Structure Material Handling System
Most portions of the supply chain don’t necessarily require customized modular material handling systems. There are instances where wholesalers, distributors, and large retail chains benefit from modular shelving and storage systems. However, manufacturers and fabricators are more heavily reliant on modular material handling systems if they want to adopt lean manufacturing, improve efficiencies, and control costs.

Unfortunately, for manufacturers, there are several inherent problems associated with a fixed material handling system like utility carts, trolleys, stock carts, or fixed shelving structures. The first issue relates to how several of these material handling solutions have welded joints or are designed and pre-manufactured to specific dimensions.

[caption id="attachment_36625" align="alignnone" width="1080"] This too heavy cart with inadequate wheels was a real source of problem for the team in addition to being a danger to their safety.[/caption]

Making any kind of adjustment to their dimensions or structure is both labor-intensive and time-consuming. This means spending a considerable amount of time having maintenance make changes. These changes often involve cutting, machining, and welding. For companies without these in-house capabilities, it means sending these structures out to third-party subcontractors.

Not only are third-party subcontractors expensive, but they can have drastic consequences on a company’s production throughput. It’s not uncommon for subcontracting to add weeks or even months for modifications to fixed structure material handling systems.

Second, as part of any continuous improvement plan, it’s common for companies to change their warehouse or shop floor layout. They may do this to reduce transit times between workstations and work cells, maximize available space, make room for a new piece of machinery or equipment, or increase their warehouse and production space to keep up with rising demand.



Once these changes are made, fixed structure systems that were pre-manufactured to specific dimensions quickly become obsolete. Companies must either cover the high costs of repair and refurbishment or purchase an entirely new material handling system.

Third, fixed structure material handling systems are by their very nature and design incapable of being flexible. They can’t be adjusted without a costly overhaul, repair, and refurbishment. This makes fixed structure material handling systems extremely problematic for manufacturers, especially ones adopting a continuous improvement mindset.
What do Manufacturers Need?
Manufacturers who adopt lean manufacturing principles need to reduce manufacturing cycle times and reduce transit times to increase production throughput. Sometimes that requires the willingness and ability to customize material handling systems for new product lines or new projects. Unfortunately, that’s not possible with fixed structure material handling.

Manufacturers must optimize their material handling systems throughout the entire production process. This means properly handing and storing incoming raw materials, while also improving the accessibility of those materials and consumables in lean work cells. Next, they need to reduce the transit times for semi-finished parts to adjacent work cells. When the entire material handling process is optimized, the company reduces waste, lowers manufacturing cycle times, and encounters fewer production delays.
The Benefit of a Modular Material Handling System
A modular material handling system is one where employees can make immediate changes to the structure’s layout without encountering extensive delays. These solutions typically include modular piping and tube and joint systems that can quickly be cut, extended, and joined in a fraction of the time compared to a fixed/welded material handling structure. Sometimes these changes can take no more than a couple of minutes.

Unfortunately, adjusting fixed material handling systems typically involves a substantial amount of industrial cutting, machining, and welding which can take days and weeks to complete. Modular systems are cost-effective solutions that are easy to assemble and disassemble without having to worry about extended lost time.
Improving Material Handling for Manufacturers



There are two essential criteria for optimizing material handling across the entire shop floor. First, a material handling structure inside lean work cells should be designed for minimal worker movement. This means parts, tools, materials, consumables, and semi-finished parts are easily accessible to production employees from within their work cells.

Second, the material handling equipment outside the work cell should be just as functional and easy to use as those inside the work cell. This ensures that transit times to move work-in-process parts to the next lean work cell in the production process are minimized.

When both the inside and outside of all lean work cells have optimized material handling structures and material handling equipment, it has the cascading effect of lowering production cycle times across the entire shop floor. After all, a single delay from a production work cell causes the next cell in the chain to experience delays until eventually, every chain in the process is behind schedule.
What can we build with a Modular Material Handling System?
There is simply no shortage of modular material handling systems that companies can make on their own using pipe and tubing systems. These products are perfect complements to a company’s constantly changing manufacturing environment. Without these modular piping solutions, companies would be faced with the high costs and delays of fixing, repairing, refurbishing, and re-welding older material handling equipment, or worse, having to purchase new ones.
Modular and Scalable Flow Racks
Most often associated with inventory and warehousing, material handling flow racks can also be placed in, or immediately outside of, lean manufacturing work cells. Having materials, parts, and consumables stationed in flow racks adjacent to work cells eliminates wasted transit times for employees from the work cell to the warehouse and back again. In essence, these material handling flow racks can sometimes act as small inventory retainers so that employees don’t waste time walking long distances for the materials they need to finish a work order.

Flow racks have an inclined design which makes it easy for employees to access the materials and parts inside production bins. Modular material handling flow racks empowers manufacturers to make relatively quick adjustments to the flow rack to account for a larger bill of materials. This could involve disassembling a portion of the flow rack to add more levels to handle more bins, or widening the length of each rack.
Modular and Scalable Carts

Carts have a multi-purpose function as material handling equipment. First, they help warehouse employees manage, move and store incoming shipments while also helping to prepare outgoing shipments.

Second, they are often essential for moving semi-finished parts and assemblies to and from separate work cells on the shop floor. Sometimes those semi-finished parts can be quite large, wide, or long. Third, they are ideal solutions for moving multiple production bins, parts, and materials for different work orders to different shop floor locations.

While carts have multiple uses, a modular and scalable cart built with tube and joint systems expands those uses and benefits ten-fold. Manufacturers know that nothing is static or stationary on the shop floor for long. Being able to adjust a cart’s size, height and width isn’t a luxury – it’s a necessity. Modular piping solutions empower manufacturers to adjust to any change in requirement.
Modular and Scalable WorkStations

Workstations are the all-important building block of any lean manufacturing work cell. A poorly-made or badly-designed workstation leads to endless wasted time as employees search in vain for poorly-placed parts, tools, instructions, bins, materials, or work orders. All this wasted time reduces operational efficiency.

If the workstation isn’t designed or structured around 5S principles (Sort, Set in Order, Shine, Standardize, Sustain) or worse, is not movement-friendly, then it’s no longer a lean workstation.

As important as a clean workstation is, it’s nowhere near as important as being able to adjust the workstation with modular piping solutions. Invariably, the workstation’s design will need to be changed, or modified at some point, and a fixed structure workstation is extremely difficult to adjust without encountering wasted time and high costs.
Modular and Scalable Racks

Racks are critical for holding inventory within warehouses. Not only do racks help to protect inventory, but their loading capacity means they can hold inventory for long periods. A higher loading capacity means each level protects the inventory on that level and each subsequent level beneath it.

It would be great if you only needed one type of rack with perfectly spaced levels that never need to change, but that is rarely the case. This is why a modular and scalable rack is so important.

Tube and joint systems allow you to create a tailor-made rack with individual levels you can adjust. Since inventory costs are typically based on warehouse square footage, a modular rack system allows you to free up valuable warehouse space, thereby reducing warehousing and inventory costs.

There is nothing more costly or time-consuming than having to change a fixed warehouse racking system. Modular racking can be made to fit the exact size and space you need to store materials, parts, and finished goods and are scalable and adaptable to support any change.
Types of Materials used to build a handling system
There are material handling systems that are pre-manufactured to specific dimensions and made with different types of materials. Ultimately, understanding the pros and cons of these materials is needed to better understand if they are viable solutions for your handling needs.

Aluminum Extrusions:

Aluminum is a lightweight, high-strength, and durable material that often has strong corrosion resistance. It is often used in manufacturing material handling equipment provided the aluminum is properly taken care of. Unfortunately, that is often the problem with a material handling structure manufactured from aluminum. Should that aluminum get stretched – which will eventually happen – then the aluminum’s surface layer will oxidize and corrode.

It’s also not uncommon for aluminum to experience water staining with high magnesium-aluminum alloys staining the most. While this doesn’t necessarily degrade the material’s properties, it is an obvious eye-sore that is less than appealing. Just imagine customers seeing water stains on every single aluminum material handling system you have.

Welded structures:

There are plenty of material handling systems that are welded. Unfortunately, these welded structures make the structure’s physical dimensions permanent. Any pre-manufactured or fixed material handling equipment is not easy to adjust or change. In fact, they aren’t designed or supposed to change.

These structures have a role to play for companies like distributors, retailers, or resellers who offer high volumes through a small number of product lines. If these product lines rarely change, then welded structures might work. Unfortunately, business change is commonplace, and welded structures aren’t just expensive to purchase – they’re expensive to fix and replace.

Standard Hardware Store Structures/Shelving:

An argument can be made for hardware store storage and shelving systems. They do play a role in inventory management. However, that role is extremely limited. It’s not uncommon for warehouses to have small shelves that hold small consumables like tape, hammers, nails, scissors, labels, etc. Unfortunately, that’s about it. These systems do not have sufficient load capacity on each shelf which means weight distribution across that shelf is very limited and extremely problematic.

Wooden Structures:

While rarely used, some companies create material handling equipment, workbenches, and workstations out of wood. Unfortunately, this is neither a good material nor a stable material to withstand the heavy loads and repeated use so common in warehouses and production shop floors. Gradually, over time, wood rots, especially when it’s exposed to humidity. As the rot propagates, the wood degrades even further and becomes weaker until eventually, it cracks or breaks. Even in a temperature-controlled warehouse, wood shelving is not a long-term viable solution.
Modular Material Handling Solutions Check all the Boxes
Companies nowadays have multiple concerns. It’s not just about making a good product, building a brand, and keeping customers. While each of these is important, there are other issues today’s companies are starting to take more seriously. Fortunately, a modular material handling system can address all these issues and more.

Ergonomic and Safe Solution

Employee absences due to work injuries are extremely expensive. The typical manufacturer covers $1,000.00 of additional costs every day an employee is injured. When employers adopt ergonomic principles, it immediately has an impact on employee engagement. Their efficiency, productivity, and attendance all improve. In return, companies don’t have to cover as many costs for absences due to injury.

For many industries, a modular material handling system is part of their overall ergonomic strategy. These are the companies that will incorporate anti-fatigue matting solutions inside work cells to provide improved impact resistance for employees. When tube and joint solutions are used alongside anti-fatigue matting solutions, then companies can easily adjust and cut both to accommodate the other.

Modular material handling systems are relied upon because their surfaces, corners and the entire structure is clean, free of burs, and void of any sharp edges. This means modular handling systems are not only ergonomic but safe for use.

Inexpensive Solution Compared to Fixed Structures

Companies faced with modifying fixed structure material handling equipment incur substantial costs and delays. Changing or adjusting fixed material handling systems often involves a tremendous amount of labor-intensive and expensive work.

Simply put, modular piping solutions are easier and faster to assemble, require less expertise, and are nowhere near as expensive or take anywhere near as long as having to send fixed structures to subcontractors. These systems can easily be assembled in-house and adjusted in a fraction of the time compared to a fixed structure material handling system.

Easily Recycled – If needed

Modular handling systems aren’t just easier to work with. While having a system that’s easily customized and adaptable is a definite plus, another benefit includes the ease with which modular systems can be recycled. This is but another way for companies to showcase their environmental stewardship.

The piping and square piping is typically made from steel with a polyethylene coating or a highly-scratch-resistant paint coating. Roller tracks are made from steel or Polyvinyl chloride (PVC) plastic. Joints are also made of steel. Finally, the end caps, pipe connectors, and hinge brackets are either made of PVC or other highly-durable plastic. Ultimately, the result is a material handling solution that is scalable, adaptable, affordable, and recyclable.

Designed with Efficiency in Mind

Modular material handling solutions are designed with efficiency and lean concepts in mind. Companies providing these tube and joint systems are well-aware of how businesses need a scalable and modular solution. These structures can be assembled and disassembled in a fraction of the time when compared to other material handling solutions made from other materials. Ultimately, it’s about enabling companies to make their own changes and structures as they see fit.
Choosing the Right Solution
Choosing a material handling system comes down to defining the type of business you run, the customers you serve, and the market or industry you operate in. Manufacturers have an obvious benefit from using modular material handling systems. However, if you are a small retailer, then modular systems aren’t likely to add any benefits or efficiencies. If you’re a business that sells a few product lines and those product lines never change, then fixed structures might be a solution. However, if your business is constantly changing and continuously growing - and if you know first-hand that fixed structure material handling has not worked for you - then modular systems may just be what you need.

Standard and Non-Standard Surfaces at Flexpipe

Standard and Non-Standard Surfaces at Flexpipe

There are several steps to designing a Flexpipe modular structure. One of them includes choosing the material you’ll use. You’ll need this information to determine how many pipes you’ll need, how many connectors and accessories you’ll use, and most importantly, whether you want your structure to have surfaces.

This article will outline the four types of surfaces that Flexpipe offers, and some others used by our customers.
The Flexpipe Standard
Despite the unprecedented number of existing surfaces, at Flexpipe, we have defined a standard of four surfaces. These four surfaces meet most of our customers' needs. The following list includes these four and other surfaces our customers use.

*For the installation of surfaces, with 1/2" surface you can use either F-SF81 from the top or AO-EMT1 and F-S81/2 and for 1/4" surface you can install them with F-SF81 from the top or with help of different accessories with some bolts like the AI-CORNER or the AI-SUPPORT.*
1. HDPE
Pricing: $$$

Due to its flexibility, high-density polyethylene (HDPE) is the most commonly used surface in Flexpipe structures. Used to make workstation tops, it’s also a great material to make drawers, shelves, or even footrests. HDPE comes in several colors and formats. Flexpipe offers 48” x 96” sheets of ½ or ¼-inch thick in white or black. Long considered the surface of choice when making modular systems, HDPE is highly resistant and solid. It’s important to note that black HDPE is less expensive because it’s recycled.

2. The Aluminum Composite
Pricing: $

Aluminum composite is a 1/16-inch thin sheet of HDPE pressed between two 1/32-inch aluminum sheets. Because it’s so thin, Aluminum composite can easily be damaged. This means it is better used as a shelving solution or to close off the sides of a structure – instead of using it for the top of a workstation. This surface has two different finishes: a matte side and a shiny side. It comes in a 48” x 96” and 1/8” thick sheet.

3. Acrylic sheet
Pricing: $

Less popular than other surfaces, acrylic sheets are more often used as separators (e.g., between a cashier and a customer) or as a protective screen against debris (e.g., installed behind a miter saw to prevent wood chips from flying away).

4. Pegboard
Pricing: $$

Used to complement structures, the pegboard hangs objects using small hooks inserted directly into the pegboard. It is more often used with workstations or shadow boards.

Non-Standards
The following surfaces are not part of the Flexpipe standard. However, they have been used by Flexpipe in some manufacturing projects at the request of our customers.
1. UHMW
Pricing: $$$$

UHMW stands for ultra-high molecular weight polyethylene. This type of HDPE has electrostatic discharge (ESD) protection. This surface protects against electrostatic shocks between people and the structure or between people and the product. UHMW is mainly used by Flexpipe customers who manufacture electronic products.

2. Plywood
Pricing: $$

A less popular material but less expensive option is wood or plywood. While plywood is easily accessible and has some positives, such as its price and protective ESD properties, it also has some negatives. Among them includes the fact that plywood can be easily damaged. It’s also more challenging to work with when compared to plastic. Finally, it’s susceptible to liquids and moisture.

3. Prefabricated
Pricing: $$

Although many people design their structures and then plan their surfaces, some prefer to build their structures from a surface. For example, they find a surface they would use for a workstation or a desk and then work to create a structure that will adapt perfectly to that surface.

Conclusion
Regardless of the type of surface you choose, your choice must be ideal for your job. If you still doubt your choice, you can quickly contact us through the chat at the bottom right of this page or contact the project manager in your area. To find the nearest project manager, visit the contact page.

Best tools to cut deckings

Best tools to cut deckings

Assembling any Flexpipe structure invariably means cutting deckings. Your goal is to have deckings that is clean, safe, and free of sharp edges. So, what type of equipment do you need to cut your deckings? Fortunately, there are multiple solutions you can use.

We’ve put together a list of the most common tools Flexpipe and our customers use when cutting deckings.

*To provide the best possible cut for every surface, Flexpipe uses blades for woods with 60 carbon teeth. Most of the equipment we’ll cover is likely equipment you already have.*
Performing the First Cuts
1. Panel Saw / Vertical Saw
This often-used and universal tool can be found in any hardware store or construction site. The panel saws allow you to cut multiple surfaces with minimal interference or problems. We use it to cut large surfaces such as 48” x 48”, 48” x 72”, and 32” x 96” etc.

2. Table Saw
Table saws allow us to cut small or large surfaces. It is an extremely versatile and relatively inexpensive solution that most manufacturers either have already or can afford. You can cut surfaces measuring 2” x 10” or as large as 48” x 72”.

3. Circular Saw
The circular saw provides a simple and immediate solution when making Flexpipe deckings. It allows us to cut tight corners and angles on both large and small surfaces. We can also perform vertical cuts on wide surfaces . However, special attention is required when using hand tools so be sure to be extremely careful.

4. Miter / Bevel Saw
Flexpipe doesn’t typically use miter or bevel saws but there are a few instances where we need them to cut small surfaces and corners. It’s not a high-use tool but it can help in some circumstances.

5. Band Saw
While Flexpipe doesn’t often use Band Saws, they are still useful when it comes to cutting specific shapes – other than just square or rectangular cuts. We also use it at times to make precision cuts on small surfaces or to make rounded corners.

6. Jigsaws
While some may claim that band saws and jigsaws can perform the same type of cut, for Flexpipe, the jigsaw provides an advantage that Band Saws don’t. First, as a hand-held tool, you have greater control and can make more precise cuts. However, again, it’s important to be careful when using hand-held tools.

7. Hole Saws
Hole saws are most often associated with hand-held drills. They aren’t used for cutting straight lines but are used to cut out circular rings in materials. This means you can use them to remove material within the circular cut to install connectors or to pass tubes. It can also be used to make edges round but doing this means you’ll need the circular saw to finish the job.

Finitions of the surface
Now that we’ve taken care of the cutting, we need to move on to finishing. Regardless of whether you want to make a shelving unit, drawer, or workstation, you’ll ultimately need to make sure the surface is free of debris, is smooth, and doesn’t have any burs.

Flexpipe relies upon two tools for finishing. We use them to ensure our decking does not have any sharp edges or protruding parts. The goal with any final Flexpipe structure is to ensure that it is finished properly and safe for use by our customers and their employees.
1. Right Angle Die Grinder
This is another hand-held too so be careful during use. This tool is ideal for sanding down uneven connections between two surfaces and providing a smooth finish. This is especially useful if you’ve used a saw that doesn’t leaves a smooth surface or leave cut marks.

2. Hand-Held Deburrer
A deburrer is another handheld tool that helps remove sharp edges. It’s also ideal for working on corners that are considered too square for other tools. For sharp edges and round corners, using anything else but a deburrer could cause problems or even injuries to employees.

Conclusion
Always be sure to draw an outline or generate a schematic of your decking long before you start any cutting. This will help you choose the right tool for the right job.

Each of these tools has either been used in-house at Flexpipe or by our customers. They are the most common tools used and will help you manufacture your Flexpipe solution from A to Z with minimal problems. If you want to learn more about how to work with the Flexpipe modular system, we invite you to read our articles on the best tools for pipe cutting and the best tools for assembly.

Don’t have the tools in house to cut your Flexpipe material? Or, the order volume is not large enough to justify the purchase of a stationary band saw? This is the opportunity to take advantage of our cutting service.

Borrowing Lean Manufacturing Concepts from the Automotive Industry

Borrowing Lean Manufacturing Concepts from the Automotive Industry

Jerry Collins – a mechanical engineer with 28 years of experience in the automotive industry – uses the pre-production stage as the critical first step to managing future production costs. It’s during this pre-production stage that Jerry uses modular piping systems as a way to layout his production floor and design material handling systems. This reduces costs and makes it easier to modify those handling systems (if needed) once full-scale production starts.

LISTEN: Audio Interview Jerry Collins
In this interview, Society of Cost Engineers founder Jerry Collins explains to Flexpipe project manager Temie Fessa how modular material handling systems have helped him maximize efficiency and profits.

Your browser does not support the audio element.

Find out how any company in any industry can benefit from using tube and joint systems in the pre-production stage as a way to manage costs.
The Origins of Lean Manufacturing
Lean manufacturing can trace its roots back to Henry Ford’s infamous Model T assembly line and the Toyota Production System (TPS) of the early twentieth century. Sometimes referred to as “lean production” or “just-in-time manufacturing”, lean manufacturing focuses on increasing production throughput while controlling costs and minimizing waste.

With lean manufacturing, companies can increase production throughput without sacrificing their cash position or purchasing excessive inventory. Unfortunately, a large number of companies use some lean concepts while never fully implementing others.
Using Modular Piping for a Mocked Assembly Line
Instead of using lean manufacturing principles during the pre-production stage, several companies only adopt lean concepts long after production has started. Unfortunately, this puts them in a read-and-react position where unforeseen changes in product designs force them to make haphazard and extremely costly adjustments. However, Jerry took an entirely different approach.

[caption id="attachment_38531" align="alignnone" width="1000"] A production line simulation using cardboard boxes. Source: Robert Simonis[/caption]

Jerry and his team used modular piping solutions to create a mockup front axle and rear axle assembly line for General Motors. As stated by Jerry, “long before we purchased any equipment, we created a whole facility with modular piping and decided early on how our material handling systems would be structured.” This included using tube and joint systems to create mock machines and equipment in order to create a visual presentation of both on the shop floor.



They also used modular piping to create trolleys to test the transit times between work cells, all the while looking for any possible obstructions. They then created temporary structures in order to simulate how future material handling systems would be positioned beside work cells, equipment, and machinery.
Making Immediate Adjustments within Minutes – Not Days or Weeks
[caption id="attachment_38508" align="alignnone" width="1440"] A dedicated material handling shop will allows you to modify quickly and on spot structures that need adjustments[/caption]

Jerry and his team of engineers chose modular piping solutions during the preproduction stage because of how easily it was to make simple changes. Some of the changes they made to their mock layout took mere minutes, something that is completely impossible to achieve with fixed material handling systems. As Jerry stated, “companies need to plan their material handling systems early on so they can maintain and improve upon their profits margins later.”

Ultimately, the tube and joint solutions replaced all of their larger, fixed-structure material handling frames. According to Jerry, making a single adjustment to their older material handling structures involved sending their heavy-duty racks to “a third party for welding and adjustments which could take weeks and months, whereas if you have a product like Flexpipe, it can be done in an afternoon.”

For Jerry and his team, adopting modular piping systems during the pre-production stage ensured everybody was comfortable with using the solution once production began. So, what are the inherent benefits of using modular piping during the initial pre-production stage?
Adopting Lean Principles in the Pre-Production Stage
Adopting lean concepts in the pre-production stage by using tube and joint systems has three primary benefits. First, it amalgamates the costs associated with laying out the entire production floor for equipment and machinery, while totaling the costs for standing structures, workbenches, shelving, trolleys, flow racks, boards, etc.

This provides companies with a complete picture of their costs. It also allows companies to decide upon how much actual square footage they need for manufacturing. They can avoid the extra costs of leasing/buying too much production space, or conversely, avoid the high costs and delays that come from not having enough production space.

Second, using modular piping solutions in pre-production helps to simplify workflow. Companies have a much easier time choosing which modular piping solutions are needed for all their T-shaped, U-shaped, and S or Z-type work cells. This allows them to maximize the transit times between production work cells, equipment, machinery, and other standing structures. It also helps them choose ideal locations for inventory and part storage.

Third, by adopting tube and joint systems in the pre-production stage, employees are better able to make quick modifications to standing structures and material handling systems once production begins. No more waiting on welding or having to send out heavy-duty racks to third-party suppliers for modifications that may take weeks or months. Instead, with tube and joint systems, the employees can make the changes themselves.

Modular piping is a product designed with lean concepts in mind. Making changes to modular material handling systems is faster, simpler, and far less expensive when compared to fixed-structure systems.
Simple Steps to Using Modular Piping During Pre-production
Again, any company in any industry can use the same approach. It simply comes down to using the following four steps.

1. Use Spaghetti Diagrams to Define Workflow

Spaghetti diagrams allow you to map your workflow so that you have a visual presentation of how physical parts move between part storage, material handling systems, work cells, equipment, and machinery. The goal is to have a sequential process where the parts move naturally and employees aren’t required to walk extremely long distances to move those parts to the next chain in the process.

2. Gather Information About Machinery & Equipment

Defining the physical size of equipment and machinery is an important aspect of maximizing available shop floor space. You’ll need to define the physical dimensions of equipment and machines and visualize how they will be laid out on the shop floor.

3. Define the Number of Material Handling Systems

Once you’ve defined the areas of your shop floor occupied by machinery and equipment, it becomes easy to determine the number of material handling systems you’ll require. To help you in the design of those systems, Flexpipe has created the Flexpipe Creator Extension, an innovative software-based solution that allows you to simplify your designs.

4. Simulate Transit Times

By now, your shop floor should be mocked up with locations for equipment, machinery, standing structures, work cells, and material handling systems. A proactive final step involves simulating transit times between each of these structures to ensure that there is sufficient space for employees to move parts and that the distances they travel aren’t too far.

Flexpipe: Make it Work For You
Flexpipe is an industry leader in tube and joint systems with a strong North American footprint. Long recognized as an innovator, Flexpipe is well-known for its affordable modular piping solutions (30% less expensive) and its customer-centric approach to customer service and after-sales support.
